77900-SNA-K02 77900-SNA-K52 Automotive Clock Spring Airbag For Honda Civic

Basic Information
Place of Origin: China
Brand Name: MHC AP
Model Number: 77900-SNA-K02
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Neutral Packing or As Requirement
Delivery Time: 3 work days after receiving payment
Payment Terms: T/T, Western Union,Paypal,
Supply Ability: 1000pcs per month
OEM Number: 77900-SNA-K02 Part Name: Clock Spring
Suitable Car: Honda Civic Condition: 100%new
Sample: Available
High Light:

77900-SNA-K52 Automotive Clock Spring

,

Honda Civic Automotive Clock Spring

,

77900-SNA-K02 Auto Clock Spring

OEM 77900-SNA-K02 77900-SNA-K52 Automotive Clock Spring Airbag For Honda Civic





Specification:



Model Number: 77900-SNA-K02 77900-SNA-K52

Part Name: Clock Spring

Suitable car: Honda Civic

Size:  Standard Size

Warranty: 12 months

Stocks: Available
Packing: Neutral Packing

Condition: 100% new





Matching car information:



Year Make Model Body & Trim Emission & Transmission
2011 Honda Civic 2 Door DX, 4 Door DX KA 5AT, KA 5MT
2010 Honda Civic 2 Door DX, 4 Door DX KA 5AT, KA 5MT
2009 Honda Civic 2 Door DX, 4 Door DX KA 5AT, KA 5MT
2008 Honda Civic 2 Door DX, 4 Door DX KA 5AT, KA 5MT
2007 Honda Civic 2 Door DX, 4 Door DX KA 5AT, KA 5MT
2006 Honda Civic 2 Door DX, 4 Door DX KA 5AT, KA 5MT





More Popular Product :



77900-SNA-K02 77900-SNA-K52 Automotive Clock Spring Airbag For Honda Civic 0







What is the clock spring ?



An airbag clock spring is used to connect the steering wheel to other electrical devices such as the airbag safety system, radio volume and station selections, horn and cruise controls. A clock spring can become faulty when wires become worn and break causing a short or open circuit. This can cause the airbag warning light to come on. Horn, radio controls and cruise controls can also stop as well.





What is the Symptoms of a bad clock spring?



Here is a list of some of the most common problems :

Airbag light is on: The airbag or SRS light turning on. A common problem often caused by a defective clock spring. If you scan the airbag system using a diagnostic scanner you may get any of the following errors:

Driver Airbag Squib Circuit High Resistance

Airbag circuit resistance too high

Driver Side Air Bag Circuit High Resistance or Open

Driver squib circuit open!





What is the locations of clock spring?



The clock spring is located in the steering column and is mounted right underneath the steering wheel. The clock spring has wires that connect to the airbag and steering wheel buttons and on the opposite side has an electrical wire harness plugged into it.





How do we confirm that clock spring is in the zero position during transportation and installation?



There are several types of clock springs. Each type has a different way of neutral position. Generally, the label or plastic parts on the clock spring will write it. Generally, it is written that the inner ring of the clock spring is rotated clockwise (or counterclockwise, which is related to the design) to the end, and then how many turns are reversed (2, 2.5, and 3 are possible) to make the plastic The two shell centering symbols are aligned, expressed as a neutral position, which is the zero position you say. Be sure to read the alignment instructions on the clock spring!
